How to connect Panasonic PBX systems to the PC via LAN port?

1. Pbx Unified Maintenance Console Application Not Found Within
2. Pbx Unified Maintenance Console Application Not Found Windows 10
3. Pbx Unified Maintenance Console Driver Soft Not Found
4. Pbx Unified Maintenance Console Application Not Found Guilty

You can connect your Panasonic PBX via LAN Port to Call Accounting Panasonic PBX collector software installed the computer.If your PBX one of the following models :

PBX Settings

Step 1- Go to Maintenance – Main.
Step 2- Set Port to LAN.
Step 3- Under Print Information select which items you would like to display in the SMDR Printout.
Step 4- Date format: MM-DD-YY.
Step 5- Time format: 24H.

Step 6- Click on SMDR Options tab.
Step 7- Note the default SMDR Port Number and Password.

Step 8- Configure collector software user and password and IP address.
By default, the Panasonic system requires a username/password (default: SMDR/PCCSMDR)

• I have using this Maintenance console V 3.0 with my Panasonic KX TEM 824. First i have reset the PABX and then i will connect to tha PABX with Maintenance console V 3.0. After this my friend call me on line phone and PABX will received auto call after 2 second and all extension number are ringing on incoming call.
• I have installed the Unified Maintenance Console on my (Windows XP) laptop. This all works fine until I come to connect. I select USB and enter the password and it returns with 'EA04201 Driver soft not found'. I have tried re-installing the software and another (XP) laptop but to no avail. How can I resolve this issue? Many thanks, YoungCodger.
• PBX Unified Maintenance Console is commonly installed in the C: Program Files Panasonic folder, however this location may differ a lot depending on the user's choice while installing the application.
• You can define the 'Operator' using the Maintenance Console application: How does the 'Incoming call pop-up' feature works? Every CRM user has PBX extension number defined in CRM. So when use's phone is ringing the incoming call notification pop-up appears. How do I disable call handling on certain external lines?

Panasonic NS Series SMDR settings

1-Login to your web maintenance console.
2-Go to 11-Maintenance section and click on main.

3-Make sure following settings are correct:
Type => to A or C. Make sure you have same settings in PBXDom side.
Port => LAN(TELNET)
Outgoing Call => Print
Incoming Call => Print
Intercom Call => Print

Open the KX-TDE Maintenance Console and go to: Maintenance SMDR. SMDR Type: TYPE C Outgoing Call Print: Print Incoming Call Print: Print Intercom Call Print: Print Log-in/Log-out Print: Print ARS Dial (Automatic Route Selection): Dial after ARS Modification CallerID Print format: Name + Number DDI/DID Print format: Name + Number.

4-Go to SMDR options tab.

5-Make sure about SMDR port number and SMDR password.
Default SMDR port number is 2300
Default SMDR password is PCCSMDR

For more information read TCP/IP client connection.

Also, you can read the following pages about Call Accounting Software for Panasonic PBXes: Quran with urdu translation mp3 free download qari sadaqat.

• User Performance Widget – Call Analytics - 2020-11-05
• PBXDom Call Analytics,iOS and Android app update - 2020-08-31
• How to connect Power BI to any Phone System - 2020-08-17

Panasonic KX-TDE100 setup PBXDOM cloud call accounting service

Configuration collector software

baud rate 19200
data bits 8
parity none
stop bits 1
flow control hardware

PBX Settings

Open the KX-TDE Maintenance Console and go to:

Maintenance > SMDR

Pbx Unified Maintenance Console Application Not Found Within

SMDR Type: TYPE C
Outgoing Call Print: Print
Incoming Call Print: Print
Intercom Call Print: Print
Log-in/Log-out Print: Print
ARS Dial (Automatic Route Selection): Dial after ARS Modification
CallerID Print format: Name + Number
DDI/DID Print format: Name + Number
Secret Dial: Print dialled number
Privacy mode: Print Dialled Number
Date Format: YY-MM-DD – named as international format

Pbx Unified Maintenance Console Application Not Found Windows 10

Maintenance > Miscellaneous

Pbx Unified Maintenance Console Driver Soft Not Found

RS-232C: Baud Rate: 19200
RS-232C: NL Code: CR+LF
RS-232C: Word Length: 8bit
RS-232C: Parity Bit: None
Error Log Information Print: Print

System > Date & Time

Change the date and time to current ones.

Pbx Unified Maintenance Console Application Not Found Guilty
